As transportation systems, event venues, tourist attractions, and smart buildings continue to digitize their operations, traditional ticket scanners are no longer sufficient. Organizations increasingly require intelligent validation terminals capable of supporting multiple identification technologies, cloud connectivity, and customized software integration.

YunBlaze provides a next-generation Custom Ticket Validator Machine with SDK and API, combining QR code validation, NFC ticketing, RFID card reading, AI recognition, and real-time communication into a single industrial-grade platform.

Designed for OEM and ODM projects, our solution helps system integrators, software developers, and smart city operators rapidly deploy advanced ticketing and access control systems.

One Device, Multiple Validation Methods

Unlike conventional ticket scanners, the YunBlaze Smart Validator supports multiple authentication technologies.

QR Code Ticket Validation

The integrated high-speed scanner supports:

• Dynamic QR Codes

• Static QR Codes

• Mobile E-Tickets

• Electronic Boarding Passes

Ideal for:

• Public transportation

• Event management

• Tourist attractions

• Visitor check-in systems

NFC & RFID Validation

The terminal supports:

• ISO14443 Type A

• ISO14443 Type B

• FeliCa

• LEGIC

• MIFARE Classic

• T=CL Protocol

This enables compatibility with:

• Transit cards

• Employee cards

• Membership cards

• Campus cards

• Government smart cards

AI-Based Identification

The platform can be equipped with adaptive visual recognition algorithms including:

• Face Recognition

• Palmprint Recognition

• Fingerprint Recognition

Custom AI models can also be integrated according to project requirements.

This makes the validator suitable for high-security access control and identity verification applications.

Powerful Hardware Architecture

The validator is powered by a high-performance multicore processor:

Processor

• Multicore ARM Cortex-A7 @ 1.2GHz

• Built-in NPU (Neural Processing Unit)

Operating System

Supports:

• Linux

• Qt Framework

• Android OS

Memory

• RAM: 2GB LPDDR

• Storage: 16GB eMMC

This architecture provides sufficient computing power for real-time ticket validation and AI recognition.

Advanced Security and Encryption

Security is critical for ticketing and payment systems.

The device supports multiple encryption algorithms:

• HASH

• MD5

• DES

• AES

• RSA

• ECC

• SM2

These security mechanisms ensure safe communication between terminals, cloud servers, and payment platforms.

Comprehensive Connectivity

The YunBlaze Ticket Validator is designed for deployment in both fixed and mobile environments.

Wireless Communication

• 4G LTE

• 3G

• 2G

• WiFi IEEE 802.11 b/g/n

Satellite Positioning

Integrated GPS module supporting:

• GPS

• BeiDou Navigation System

This makes the device ideal for bus fare collection and fleet management applications.

Ethernet

• 10/100 Mbps Adaptive Ethernet

Industrial Interfaces

• USB Host ×1

• USB Device ×1

• RS232 ×1

• RS485 ×1

• CAN Bus (Optional)

• Wiegand Interface ×1

• Relay Output ×1

• Switch Input ×1

The extensive interface options allow easy integration with gates, turnstiles, ticketing systems, and access control platforms.

High-Visibility Display and Voice Guidance

Display Options

Standard:

• 4.0-inch TFT LCD

• 480 × 800 Resolution

• Outdoor Readable

Optional:

• 4.5-inch TFT LCD

• 720 × 1280 Resolution

Audio Prompt

Supports:

• TTS Voice Broadcasting

• Single Channel Speaker

• 2W Audio Output

LED Status Indicators

• Red LED

• Green LED

These features improve user interaction and operational efficiency.

AI Camera System

The validator includes an advanced AI camera module featuring:

• Dual CMOS Sensors

• MIPI Interface

• DVP Interface

• White Fill Light

• Infrared Fill Light

The camera system enables high-performance face recognition under various lighting conditions.

SDK and API for Rapid Integration

One of the key advantages of YunBlaze solutions is the availability of comprehensive SDK and API support.

SDK Functions

Developers can access:

• QR Code Scanner Control

• RFID Reader Functions

• FeliCa Card Operations

• AI Recognition Modules

• GPS Data Access

• Network Management

• Relay and Peripheral Control

Development Frameworks:

• Android Java SDK

• Qt SDK

• Linux SDK

RESTful API Integration

The API enables seamless integration with:

• Ticketing Platforms

• Transportation Systems

• ERP Software

• CRM Systems

• Visitor Management Platforms

• Smart City Solutions

This significantly reduces software development time and deployment costs.

Ideal Applications

Bus Fare Collection Systems

Passengers can:

• Tap transit cards

• Scan QR tickets

• Validate digital passes

Operators gain:

• Real-time transaction data

• Route analytics

• Fleet tracking

Event Ticket Validation

Perfect for:

• Concerts

• Stadiums

• Conferences

• Exhibitions

Tourist Attractions

Supports:

• Scenic area ticketing

• Theme park access

• Museum admission

• Visitor flow management

Smart Access Control

Ideal for:

• Office buildings

• Campuses

• Factories

• Government facilities

Industrial Design for Harsh Environments

Environmental Specifications

Operating Temperature:

• -25°C to +70°C

Storage Temperature:

• -30°C to +70°C

Humidity:

• 0~90% RH

Protection Rating:

• IP54

Physical Specifications

Dimensions:

• 190 × 140 × 50 mm

Weight:

• ≤1.5 kg

Service Life:

• More than 6 Years

Certification:

• CE

These specifications ensure reliable operation in outdoor transportation and industrial environments.

OEM & ODM Customization Services

YunBlaze offers complete customization services including:

Hardware Customization

• RFID Module Selection

• Camera Configuration

• Display Size

• Communication Modules

• Housing Design

Software Customization

• Android Application Development

• Linux Application Development

• Cloud Platform Integration

• Custom SDK Development

• API Development

Branding Services

• Logo Customization

• Packaging Design

• Private Label Manufacturing

Conclusion

The YunBlaze Custom Ticket Validator Machine with SDK and API is far more than a simple ticket scanner. It is a complete smart validation platform combining QR code ticketing, RFID card reading, AI biometric recognition, GPS positioning, 4G communication, and industrial-grade connectivity.

Whether you are developing a bus fare collection system, event ticketing platform, visitor management solution, or smart access control network, YunBlaze delivers a flexible OEM/ODM platform designed for rapid deployment and long-term scalability.
